Tuxedo 8,000 lb Rolling Jack (High Mount) – Air / Hyd | RAJ-8K-H

The Tuxedo RAJ‑8K‑H Rolling Air Jack is engineered for heavy-duty duty cycles in professional garages and alignment bays. With an 8,000 lb lifting capacity and pneumatic air/hydraulic operation, this scissor-style bridge jack effortlessly lifts axles for maintenance, brake work, and wheel alignment. Its high-mount roller body bracket is tailored for lifts with low-positioned jack rails, ensuring smooth engagement and avoiding contact with the floor when fully lowered.

Built for adaptability, the RAJ‑8K‑H boasts a universal roller body design with spring-loaded precision bearings and adjustable side guide wheels to fit low, medium, or high runways. Its telescoping support arms (38-3/8″–60″, roller body wheel center) and lifting arms (35-7/16″–57-1/2″, pad center) accommodate a range of lift widths, and lifting height is 6-9/16″ to 14-7/8″ (pad adaptor only), expandable via included height adapters (1‑5⁄16″ and 5″). These figures are from Tuxedo’s current RAJ-8K-L page, as Tuxedo does not publish a separate RAJ-8K-H page; confirm the current specification before ordering. Double air bags, a pressure regulator, locking height position, and rugged powder-coat finish combine to make the RAJ‑8K‑H both safe and serviceable.
